TV Walls That Age Well: Unit Depths, Vent Gaps & Soundbar Centerlines

Choose once, live well—depths that read slim, venting that keeps gear safe, and centerlines that make the TV and soundbar feel like one calm composition.





The Three Alignments (what “aged-well” looks like)

  • Sightline: TV center ≈ seated eye level (no craning).

  • Soundline: Soundbar below the TV, tweeters near ear height when seated (or angled up).

  • Cableline: Power + data pre-planned and invisible—wall outlets behind the TV, brush plates, and a floor outlet if the console floats.

Founder POV — Anmol Sachdeva: “Luxury on a TV wall is quiet engineering: correct centerlines, cool-running gear, and no cables.”





Depth Bands for LCD/TV Runners (India-first)

Your depth choice decides how elegant the wall looks and whether gear runs cool.

Use Case

Recommended Depth (cm)

Looks

Stores

Notes

Slim look (TV + soundbar only)

28–35

Lightest

Remotes, small hubs

Ideal for rentals and minimalist rooms

Media-ready (DTH/console)

38–45

Balanced

Set-top, game console

Full backs with cable bays; passive vents

AVR/amp capable

50–55+

Chunkier

AVR, NAS, power gear

Needs vent slots, grille fronts, and raised feet

India notes: Narrow rooms + stone floors amplify bulk. If the space is tight, hold the shallower end of each band and reclaim function with vented fronts and smart cable bays.





Ventilation & Power (safe, silent, serviceable)

Hot gear fails early. Plan air the way you plan aesthetics.

Vent rules (baseline):

  • AVR bay top clearance: ~15 cm free air.

  • Side clearance: ~5 cm each side.

  • Rear path: Perforated or louvered back plus a gap to the wall.

  • Active cooling: Add a whisper fan if you enclose multiple heat sources.

Power & data map:

  • High on wall (behind TV): 1 × power + 1 × data (HDMI/eARC) + 1 × conduit with pull string.

  • Inside runner: 2–3 × power (set-top/console/router), one brush plate to the TV cavity.

  • Floating console: discreet floor outlet under the unit (carpet grommet or flush metal plate).

  • Label both ends of every cable loom; leave one spare Ultra-High-Speed HDMI for upgrades.





Soundbar Centerlines & Heights (dialogue clarity)

  • Position: Below the TV, front edge flush with the runner fascia.

  • Height: Tweeters near ear height when seated; if lower, angle up with a wedge/feet.

  • IR & sensors: Keep ≥ 5–8 cm clearance to the TV’s bottom so sensors aren’t blocked.

  • Wiring: Short eARC HDMI lead behind the screen; no visible loops.





Mounting & Weight (VESA sanity)

  • Confirm VESA pattern & TV weight before carpentry.

  • Prefer mounts with centered patterns to reduce torque on block/brick walls.

  • Use correct anchors for masonry; avoid chasing brittle walls excessively—run a conduit instead.

  • Service loop for HDMI and power so the TV can tilt out without yanking leads.





Cable Hygiene & Future-Proofing

  • Conduits: ≥ 32 mm internal diameter to pass HDMI heads; leave a pull string.

  • Today vs tomorrow: Run at least one 48 Gbps certified HDMI (for 4K/120, eARC). Leave a spare conduit for the next standard.

  • Brush plates: At wall entries/exits—clean, IR-friendly, dust-reducing.

  • Network: If possible, give the runner a hard-wired Ethernet jack for streamers/NAS.





Glare, Colour & Surrounds (seeing what matters)

  • Glare control: Aim to cross-light the wall (side lights, not downlight hotspots).

  • Colour temperature: Keep one CCT around the TV (2700–3000 K is calm for evenings).

  • Wall finish: Plaster or stone-greige; avoid high-gloss panels that mirror the screen.

  • Art & mirrors: If you add them, offset so they don’t reflect the TV.





India-First Planning (dust, humidity, cleaning)

  • Dust: Use gasketed doors or tight overlaps on media bays; microfiber and a fine brush for vents.

  • Humidity & monsoon: Elevate power bricks; vent high and low for stack effect.

  • Stone floors: Add soft glides under floating consoles; avoid stick-on cable covers on textured stone—use proper conduits.





Layout Recipes (copy these)

1) Rental-Friendly TV Wall (no chasing)

  • Runner depth: 30–32 cm.

  • Cable cover: Surface raceway painted to wall; brush plates at both ends.

  • Power: Double outlet behind TV; one inside runner.

  • Soundbar: Below TV, angle up slightly.

2) Family Media Wall (balanced)

  • Runner depth: 40–45 cm with two vented bays.

  • Power/data: High TV outlet + eARC; inside runner with labeled looms.

  • Lighting: Offset picture light or wall washer; CRI ≥ 90 for true colours.

  • Child safety: Soft-close doors, hidden cable doors.

3) A/V Enthusiast Wall (cool & serviceable)

  • Runner depth: 52–55 cm, louvered fronts.

  • Cooling: Quiet 12 V fan pulling air up and out.

  • Service: Rear access flap; Velcro-bundled looms; spare HDMI loop.

  • Network: Ethernet hub inside; UPS in a ventilated bay.





Mistakes That Date a TV Wall

  • TV mounted too high (neck craning).

  • Soundbar on top of the TV (audio fires over you).

  • Sealed cabinet with hot gear (thermal shutdown).

  • Mixed colour temperatures around the screen (harsh, cheap feel).

  • Dangling visible cables or tiny conduits you can’t service later.





FAQs

What’s the best height to mount a TV?
 Place the screen center at seated eye level. If the sofa is very low or deep, test with painter’s tape, then mount.

Should the soundbar go above or below the TV?
 Below, aligned to the screen centerline, tweeters near ear height; angle up if it sits low.

How deep should a TV unit be for an AVR?
 Plan 50–55 cm with about 15 cm free air above, 5 cm sides, and a rear exhaust path (plus active fan if fully enclosed).

Do I need eARC / Ultra-High-Speed HDMI?
 Yes—eARC simplifies lossless audio. Run at least one 48 Gbps HDMI now and leave a spare conduit for future standards.

How do I hide all the cables neatly?
 Put power + HDMI behind the TV, a brush plate to the runner, and labelled looms inside. If the runner floats, use a floor outlet.





Summary

  • Depth bands: 28–35 cm slim • 38–45 cm media • 50–55+ cm AVR.

  • Ventilation: Top ~15 cm, sides ~5 cm, rear path; add quiet fan in sealed designs.

  • Centerlines: TV center ≈ eye level; soundbar below, ear height or angled up.

  • Power & data: High outlet behind TV, looms inside runner, spare 48 Gbps HDMI + conduit.

India-first: Plan for dust, humidity, stone floors; keep one colour temperature; no visible cables.
